Finished Product: There are two basic designs, single-wide and double wide. The single-wide cabinet is XXXmm across the front and the double wide is XXXmm across.
Both designs have 200mm between verticals on the sides. Both designs have the same style tops. Each of the single-wide and double wide can be 2 or more levels high. It is standard that the bottom level will have the Raspberry PI and control panel, but the battery back-up subsystem is also optional and may take its own level on a single-wide cabinet. |
|||
| Two port Single-wide |  |
||
| Four port Single-wide |  |
||
| Two port Double-wide | |
||
| Four port Double-wide | |
||
